INE AR 180

High recovery 180% rutile electrode

Iron-powder rutile-coated stick electrode with 180% efficiency. Designed for butt and fillet welds on medium to thick plates in shipbuilding. Very good looking weld bead and rather brittle, easily removable slag. E7024 EN ISO 2560-A: EN ISO 2560-A: E 42 0 RR 7 4
Classifications
  • AWS A 5.1: E7024
  • EN ISO 2560-A: E 42 0 RR 7 4
REQUEST LISTING
DOWNLOAD DOCUMENTS

Iron-powder rutile-coated stick electrode with about 180% efficiency. Designed for butt and fillet welds on medium to thick plates in shipbuilding yards and heavy structural steel works. Very good looking weld bead and rather brittle, easily removable slag.

C 0.07
Si 0.40
Mn 0.80
Yield strength 460 MPa
Tensile strength 550 MPa
Elongation 24 %
Impact test Kv (0°C) 60 J
Impact test Kv (-20°C) 35J
Diameter (mm) Length Ampere
3.2 450 130-165
4.0 450 180-230
5.0 450 260-300
  • piano e piano frontale
