Low alloy copper-coated solid wire designed for welding low alloy steels with 2% Ni content, fine grained for low temperature applications. Suitable for the construction of offshore platforms, tanks and pipelines, where good fracture toughness from as-welded joints is demanded down to temperatures in the region of -60°C. To be used under the shield of Ar+CO2.
C | 0.10 |
Si | 0.55 |
Mn | 1.00 |
Ni | 2.50 |
M21 | M21 | M21 | ||
Yield strength | 510 MPa | 480 (T) MPa | 480 (T) MPa | |
Tensile strength | 570 MPa | 560 (T) MPa | 560 (T) MPa | |
Elongation | 23 % | 26 (T) % | 26 (T) % | |
Impact test Kv (-40°C) | 70 J | 90 J (T) | ||
Impact test Kv (-60°C) | 50 J | 70 J (T) |
Diameter (mm) | Volts | Ampere |
0.8 | 16-28 | 60-200 |
1.0 | 17-32 | 80-260 |
1.2 | 18-34 | 100-360 |
1.6 | 19-38 | 130-450 |
