INEFIL CU

Mig Mag wires for welding weather-resistant steels.

Solid wire AWS A 5:28: ER80S-G EN ISO 14341-A: G 50 4 M21 Z Ni-Cu-Cr for welding steels resistant to atmospheric corrosion. Suitable for the construction of tanks, bridges, to be used under protective gas of Ar + CO2 mixture.
Classifications
  • AWS A 5.28: ER80S-G
  • EN ISO 14341-A: G 50 4 M21 Z
  • (EN ISO 16834-A: G Mn3Ni1Cu)
Approvals
  • Marchio CE
  • DB
  • TÜV
Finishes
  • Copper coated
REQUEST LISTING
DOWNLOAD DOCUMENTS

Low-alloy copper-coated solid wire with Ni-Cu-Cr additions designed for weather-resistant steel. Thanks to the chemical composition and weld metal mechanical properties it is also used for welding high tensile strength steels. Suitable for the construction of containers, tanks, bridges, building panels, chimneys, means of transport, offshore platforms, etc. The weld material shows a good resistance to atmospheric corrosion and salt water. To be used under the shield of Ar+CO2. MATERIALS TO BE WELDED Others A 242 1, 2 10155 S235 J 0 W (BS 4360 Gr WR50A) Corten A A 588 Gr A 10155 S235 J 2 W (BS 4360 Gr WR50B) Corten B1 A 588 Gr B 10155 S355 J 0 W (BS 4360 Gr WR50C) Italcor 1-2 A 588 Gr C 10155 S355 J 2 W steel of EN 10025-5 Resco A 588 Gr K 10155 S355 K 2 G 1 W Patinax Resista ASTM EN WELDING GUIDELINES Interpass temperature 150°C. Preheat and PWHT are not required. TECHNICAL INFORMATION Gas: Mix Ar- CO2 (EN 14175) Welding position: all positions WELDING PARAMETERS Current Diameter (mm) 0.8 1.0 1.2 1.6 Volts (V) 16 ÷ 28 17 ÷ 32 18 ÷ 34 19 ÷ 38 Intensity (A) 60 ÷ 200 80 ÷ 260 100 ÷ 360 130 ÷ 450 DC +

C 0.08
Si 0.75
Mn 1.40
Ni 0.70
Cr 0.30
Cu 0.40
M21
Yield strength 530 MPa
Tensile strength 620 MPa
Elongation 26 %
Impact test Kv (-20°C) 90 J
Impact test Kv (-40°C) 70 J
Impact test Kv (-50°C) 50 J
Diameter (mm) Volts Ampere
0.8 16-28 60-200
0.9
1.0 17-32 80-260
1.2 18-34 100-360
1.6 19-38 130-450
