INEFIL INOX 316 LSI

Solid wire for welding of stainless AISI 316

AWS A 5.9: ER316L solid wire with low carbon content for welding stainless steel at 20/10/2 Ni / Cr/Mo. The high silicon content allows for good arc stability. To be used with Ar 98% + O2 2% mixture.
Classifications
  • AWS A 5.9: ER316LSi
  • EN ISO 14343-A: G 19 12 3 L Si
Approvals
  • Marchio CE
  • DB
  • TÜV
REQUEST LISTING
DOWNLOAD DOCUMENTS

Solid wire with low carbon concentration designed for welding stainless steel with 19% Cr, 12% Ni and 2-3% Mo content with service temperature up to 400°C. Thanks to the higher silicon content its arc stability gets improved, it gives good-looking weld bead and very limited spattering. It finds application in pipes fabrication, weld overlay, vessels & boilers fabrication, ship building and marine or salt environment. Generally good resistance to corrosion, intercrystalline corrosion and to many acids. To be used under the shield of Ar 98% + O2 2%.

C 0.02
Si 0.80
Mn 1.70
Ni 12.20
Cr 18.50
Mo 2.50
M13
Yield strength 440 MPa
Tensile strength 560 MPa
Elongation 40 %
Impact test Kv (R.T.) > 47 J
Diameter (mm) Volts Ampere
0.8 16-28 60-200
1.0 17-32 80-260
1.2 18-34 100-360
