INEFIL TITAN 1

Mig Mag wires for welding of mild and low alloy steels

AWS A 5.18: ER70S-G EN ISO 14341-A: G 42 2 M21 Z Bronze-coated solid wire suitable for welding thin, galvanised or electro-galvanised plates; very limited spattering thanks to the addition of Titanium. Used under the shield of Ar+CO2.
Classifications
  • AWS A 5.18: ER70S-G
  • EN ISO 14341-A: G 42 2 M21 Z
Approvals
  • Marchio CE
Finishes
  • Bronze
REQUEST LISTING
DOWNLOAD DOCUMENTS

A non-copper-coated solid wire designed for welding carbon and carbon-manganese steels with tensile strength up to 510 MPa. Suitable as well for welding thin, galvanised or electro-galvanised plates; very limited spattering thanks to the addition of titanium and zirconium. The fusion allows the degassing of zinc vapours, which prevents the formation of blows and pores in the weld bead. To be used under the shield of Ar+CO2.

M21
Yield strength 440 MPa
Tensile strength 520 MPa
Elongation 28 %
Impact test Kv (-20°C) 70 J
Diameter (mm) Volts Ampere
0.6 15-26 50-180
0.8 16-28 60-200
0.9 16-30 70-230
1.0 17-32 80-260
