INETIG 80 Ni 2

TIG rods for welding low temperatures steel

Low alloy copper-coated tig rod designed for welding low alloy steels with 2% Ni content, fine grained for low temperature applications. Suitable for the construction of offshore platforms.
Classifications
  • AWS A 5.28: ER80S-Ni2
  • EN ISO 636-A: W 50 6 2Ni2
REQUEST LISTING
DOWNLOAD DOCUMENTS

Low alloy copper-coated tig rod designed for welding low alloy steels with 2% Ni content, fine grained for low temperature applications. Suitable for the construction of offshore platforms, tanks and pipelines, where good fracture toughness from as-welded joints is demanded down to temperatures in the region of -70°C.

C 0.10
Si 0.55
Mn 1.00
Ni 2.30
I1 I1 I1
Yield strength 520 MPa 480 (T) MPa 480 (T) MPa
Tensile strength 580 MPa 570 (T) MPa 570 (T) MPa
Elongation 25 % 27 (T) % 27 (T) %
Impact test Kv (-20°C) 150 J
Impact test Kv (-40°C) 100 J 110 J (T)
Impact test Kv (-60°C) 80 J 90 J (T)
  • TUTTE
